312421
PSSu, compact module, failsafe, special module, analysis unit forPSENvip, productive version, 1 interface PSENvip receiver, 1 interface PSENvip transmitter, 4 inputs, 2 test pulse outputs 0.25 A, 2 outputs, 1,75 A, single-pole, plus-switching, short-circuit proof, overload-proof, free from feedback, 2 outputs, 3 A, dual-pole, short-circuit proof, overload-proof, high discharge voltage, free from feedback, 2 Ethernet interfaces, 100 MBit/s.
||
-
-
Secure Shopping
100% Money Back Guarantee.
-
30-DAY RETURNS
30 Days After-sales Return.
-
Worldwide Delivery
Worldwide Fast Shipping.
General data
| Approval | CE  cULus Listed  TÜV  EAC (Eurasian)  |
| Application range | Failsafe  |
Â
Technical data
Electrical data
| Purpose of U1 | Module supply  |
| Supply voltage (V) | 5 Â V |
| Type of supply voltage U1 | DC Â |
| Power consumption DC | 5 Â W |
| Purpose of U2 | Periphery supply  |
| Supply voltage 2 (V) | 24 Â V |
| Type of supply voltage U2 | DC Â |
| Tolerance of U2 | -30 %/+25 % Â |
| Purpose of U3 | Â |
| Type of supply voltage U3 | DC Â |
| Tolerance of U3 | -30 %/+25 % Â |
Inputs
| Number of digital inputs | 4 Â |
| Number of inputs | 4 Â |
| DC voltage at input | 24 V DC Â |
| Potential isolation inputs | yes  |
Semiconductor outputs
| Potential isolation S/C O | Yes  |
| S/C output short circuit proof | Yes  |
| Perm. load 1pole Output | Resistive  Inductive  Capacitive  |
Semiconductor outputs 2-pole
| Number 2-pin SC outputs | 2 Â |
| Pot. isolation 2pole S/C O | Yes  |
| 2pole S/C O short circ. proof | Yes  |
Test clock outputs
| Number of test pulse outputs | 2 Â |
Environmental data
| Climatic suitability to ... | EN 60068-2-30 Â EN 60068-2-2 Â EN 60068-2-1 Â EN 60068-2-78 Â EN 60068-2-14 Â |
| Ambient temperature standard | EN 60068-2-14 Â |
| Ambient temperature | 0 - 60  °C |
| Storage temperature standard | EN 60068-2-1/-2 Â |
| Climatic suitability standard | EN 60068-2-78 Â |
| Humidity rating | 93 % r. h. at 40 °C  |
| Condensation permitted? | Not permitted  |
| Perm. operating height ASL | 5000 m  |
| EMC to standard ... | EN 61000-4-4 Â EN 61000-6-2 Â EN 61000-4-5 Â EN 61000-4-6 Â EN 61000-6-4 Â EN 61000-4-2 Â EN 61000-4-3 Â |
| Vibration to standard ... | EN 60068-2-6 Â |
| Acc. shock to standard1 | 15g  |
| Clearance & creepage dist. to | EN 60664-1 Â |
| Overvoltage category | II Â |
| Pollution degree clear.&creep. | 2 Â |
| Protection type standard | ENÂ 60529 Â |
| Protection type, mounting | Â |
| Protection type, housing | Â |
| Terminal protection type | Â |
Mechanical data
| Mounting position | vertical  |
| Housing material lower section | PC Â |
| Housing material front plate | PC Â |
| Connection terminal | Connector strip  |
| Terminal style | plug-in  |
| Height dimension | 128.9 Â mm |
| Width dimension | 56 Â mm |
| Depth dimension | 56 Â mm |
| Net weight | 200 Â g |
| Gross weight | 215 Â g |
Environment
| REACh compliance | contains min. 1 SVHC-substance  |
| WEEE classifikation (08/2018) | 5 devices (feed size |
Commercial data
| ECLASS version | ECLASS-9.1 Â |
| ECLASS Reference Feature | 27242604 Â |
| ETIM Version | ETIM-7.0 Â |
| ETIM Reference Group | EG000024Â Â |
