312437
PSSu, compact module, failsafe, counter, 2 operating modes,configurable, 1 input, incremental encoder, differential signal RS422, resolution 32Bit.
||
-
-
Secure Shopping
100% Money Back Guarantee.
-
30-DAY RETURNS
30 Days After-sales Return.
-
Worldwide Delivery
Worldwide Fast Shipping.
General data
| Approval | CE  cULus Listed  KOSHA  EAC (Eurasian)  TÜV  |
| Application range | Failsafe  |
Â
Technical data
Input incremental encoder
| Type of inputs incr. enc. | Incremental encoder  |
| Signal input A, B and/or C | Differential signal (RS 422) Â |
| Evaluation counter puls incr. | 2x  1x  4x  |
| Pot. isol. incr./per. supply | Yes  |
| Pot. isol. incr./mod.supply | Yes  |
Environmental data
| Climatic suitability to ... | EN 60068-2-30 Â EN 60068-2-2 Â EN 60068-2-1 Â EN 60068-2-78 Â EN 60068-2-14 Â |
| Ambient temperature standard | EN 60068-2-14 Â |
| Ambient temperature | 0 - 60  °C |
| Storage temperature standard | EN 60068-2-1/-2 Â |
| Climatic suitability standard | EN 60068-2-30 Â EN 60068-2-78 Â |
| Humidity rating | 93 % r. h. at 40 °C  |
| Condensation permitted? | Not permitted  |
| Perm. operating height ASL | 2000 m  |
| EMC to standard ... | EN 61000-4-4 Â EN 61000-6-2 Â EN 61000-4-5 Â EN 61000-6-4 Â EN 61000-4-6 Â EN 61000-4-2 Â EN 61000-4-3 Â |
| Vibration to standard ... | EN 60068-2-6 Â |
| Acc. shock to standard1 | 15g  |
| Acc. shock to standard2 | Â |
| Clearance & creepage dist. to | IEC 60664-1 Â |
| Overvoltage category | II Â |
| Pollution degree clear.&creep. | 2 Â |
| Protection type standard | ENÂ 60529 Â |
| Protection type, mounting | Â |
| Protection type, housing | Â |
Mechanical data
| Housing material lower section | PC Â |
| Housing material upper part | PC Â |
| Connection terminal | D-sub male  D-sub female  |
| Height dimension | 128.9 Â mm |
| Width dimension | 30 Â mm |
| Depth dimension | 56 Â mm |
| Net weight | 90 Â g |
| Gross weight | 105 Â g |
Environment
| REACh compliance | contains min. 1 SVHC-substance  |
| WEEE classification (08/2018) | 5 devices (feed size |
Commercial data
| ECLASS version | ECLASS-9.1 Â |
| ECLASS Reference Feature | 27242604 Â |
| ETIM Version | ETIM-7.0 Â |
| ETIM Reference Group | EG000024 |
