314191
PSSu, electronic module, failsafe, supply voltage, infeed module supply 24 V DC 2 A, infeed periphery supply 24 V DC 10 A, infeed C-rail 10 A, for increased environmental requirements.
||
-
-
Secure Shopping
100% Money Back Guarantee.
-
30-DAY RETURNS
30 Days After-sales Return.
-
Worldwide Delivery
Worldwide Fast Shipping.
General data
| Approval | CE  cULus Listed  KOSHA  EAC (Eurasian)  TÜV  |
| Application range | Standard/failsafe  |
Â
Technical data
Electrical data
| Purpose of U1 | Module supply  |
| Supply voltage (V) | 24 Â V |
| Type of supply voltage U1 | DC Â |
| Power consumption DC | 12 Â W |
| Purpose of U2 | Periphery supply  |
| Supply voltage 2 (V) | 24 Â V |
| Type of supply voltage U2 | DC Â |
| Tolerance of U2 | -30 %/+25 % Â |
| Pot. isolation UINT1 to U2 | 3050 V Â |
| Potential isolation U1 to U2 | 3050 V Â |
| Purpose of UINT1 | int. system voltage  |
| Tolerance of UINT1 | -2 %/+3 % Â |
| Max. curr. contin. oper. UINT1 | 2 Â A |
| Bridge U-interrupt UINT1 stan. | EN61496-1 Â EN61131-2 Â DIN V EN V 1954 Â |
| UINT1 short circuit proof | Yes  |
Environmental data
| Climatic suitability to ... | EN 60068-2-30 Â EN 60068-2-2 Â EN 60068-2-1 Â EN 60068-2-78 Â EN 60068-2-14 Â |
| Ambient temperature | -40 - 70  °C |
| Climatic suitability standard | EN 60068-2-30 Â EN 60068-2-78 Â |
| Humidity rating | 93 % r. h. at 40 °C  |
| Condensation permitted? | Briefly  |
| Perm. operating height ASL | 5000 m  |
| EMC to standard ... | EN 61000-4-4 Â EN 61000-6-2 Â EN 61000-4-5 Â EN 61000-4-6 Â EN 61000-6-4 Â EN 61000-4-2 Â EN 61000-4-3 Â |
| Vibration to standard ... | EN 60068-2-6 Â |
| Broad band noise to | EN 60068-2-64 Â |
| Acc. shock to standard1 | 15g  |
| Acc. shock to standard2 | 25g  |
| Clearance & creepage dist. to | EN 60664-1 Â |
| Overvoltage category | II Â |
| Pollution degree clear.&creep. | 2 Â |
| Protection type standard | ENÂ 60529 Â |
| Protection type, mounting | Â |
| Protection type, housing | Â |
| Terminal protection type | Â |
Mechanical data
| Housing material lower section | PC Â |
| Housing material front plate | PC Â |
| Housing material code | PA Â |
| Terminal style | plug-in  |
| Height dimension | 76 Â mm |
| Width dimension | 25.2 Â mm |
| Depth dimension | 60.2 Â mm |
| Net weight | 60 Â g |
| Gross weight | 69 Â g |
| Name of coding element | C Â |
| Colour of coding element | Yellow  |
Environment
| WEEE classifikation (08/2018) | 5 devices (feed size |
Commercial data
| ECLASS version | ECLASS-9.1 Â |
| ECLASS Reference Feature | 27242611 Â |
| ETIM Version | ETIM-7.0 Â |
| ETIM Reference Group | EG000024Â Â |
