314511
PSSu, electronic module, standard, digital inputs and outputs, 2outputs, relay contacts, 2 A, N/O, potential-free, for increased environmental requirements.
||
-
-
Secure Shopping
100% Money Back Guarantee.
-
30-DAY RETURNS
30 Days After-sales Return.
-
Worldwide Delivery
Worldwide Fast Shipping.
General data
| Approval | CE  cULus Listed  |
| Application range | Standard  |
Â
Technical data
Electrical data
| Permitted loads | Resistive  Inductive  |
Relay outputs
| Number of relay outputs | 2 Â |
| Utilisation cat. AC/DC1 stand. | EN 60947-4-1 Â |
| Utilisation cat. AC15/DC13sta. | EN 60947-5-1 Â |
| Safety contacts: AC at UL | 240 VAC G. P. Â |
| Contact relay fuse prot. to | EN 60947-5-1 Â |
| Relay contact material | AgSnO2 Â |
| Pot.isol. RlCont - Uint1 | 4900 V (safe separation) Â |
| Pot.isol. RlCont to U2 | 4900 V (safe separation) Â |
| Pot.isol. RlCont1 to CRail | 3050 V (basic insulation) Â |
| Pot.isol. RlCont1 to RlCont2 | 4900 V (safe separation) Â |
Environmental data
| Climatic suitability to ... | EN 60068-2-30 Â EN 60068-2-2 Â EN 60068-2-1 Â EN 60068-2-78 Â EN 60068-2-14 Â |
| Ambient temperature standard | EN 60068-2-14 Â |
| Ambient temperature | -40 - 70  °C |
| Ambient temp. with UL | 60 °C  |
| Storage temperature standard | EN 60068-2-1/-2 Â |
| Climatic suitability standard | EN 60068-2-30 Â EN 60068-2-78 Â |
| Humidity rating | 93 % r. h. at 40 °C  |
| Condensation permitted? | Briefly  |
| Perm. operating height ASL | 5000 m  |
| EMC to standard ... | EN 61131-2 Â EN 61000-4-4 Â EN 61000-4-5 Â EN 61000-4-6 Â EN 61000-4-2 Â EN 61000-4-3 Â |
| Vibration to standard ... | EN 60068-2-6 Â |
| Broad band noise to | EN 60068-2-64 Â |
| Acc. shock to standard1 | 15g  |
| Acc. shock to standard2 | Â |
| Clearance & creepage dist. to | EN 60664-1 Â EN 61131-2 Â |
| Overvoltage category | II Â |
| Pollution degree clear.&creep. | 2 Â |
| Protection type standard | ENÂ 60529 Â |
| Protection type, mounting | Â |
| Protection type, housing | Â |
| Terminal protection type | Â |
Mechanical data
| Housing material lower section | PC Â |
| Housing material front plate | PC Â |
| Housing material code | PA Â |
| Terminal style | plug-in  |
| Height dimension | 76 Â mm |
| Width dimension | 12.6 Â mm |
| Depth dimension | 60.2 Â mm |
| Net weight | 44 Â g |
| Gross weight | 58 Â g |
| Name of coding element | I Â |
| Colour of coding element | Dark grey |
Environment
| WEEE classifikation (08/2018) | 5 devices (feed size |
Commercial data
| ECLASS version | ECLASS-9.1 Â |
| ECLASS Reference Feature | 27242604 Â |
| ETIM Version | ETIM-7.0 Â |
| ETIM Reference Group | EG000024Â Â |
