328402
PSS u2, electronic module, standard, digital inputs and outputs, 16 outputs, semiconductor 0.5 A, single-pole, positive-switching, shortcircuit-proof, overload-proof, 0 V DC with additional voltage distribution module, expanded diagnostics, 1-row, terminal block PSS u2 T 16 required (not supplied with the system).
||
-
-
Secure Shopping
100% Money Back Guarantee.
-
30-DAY RETURNS
30 Days After-sales Return.
-
Worldwide Delivery
Worldwide Fast Shipping.
General data
| Approval | CE  cULus Listed  |
| Application range | Standard  |
Â
Technical data
Electrical data
| Permitted loads | Resistive  Inductive  Capacitive  |
Semiconductor outputs
| DC voltage at output | 24 V DC Â |
| Potential isolation of S/C O | Yes  |
| S/C output short circuit proof | Yes  |
Environmental data
| Climatic suitability to ... | EN 60068-2-30 Â EN 60068-2-2 Â EN 60068-2-1 Â EN 60068-2-78 Â EN 60068-2-14 Â |
| Ambient temperature standard | EN 60068-2-14 Â |
| Ambient temperature | 0 - 60  °C |
| Storage temperature standard | EN 60068-2-1/-2 Â |
| Climatic suitability standard | EN 60068-2-78 Â |
| Humidity rating | 93 % r. h. at 40 °C  |
| Condensation permitted? | Not permitted  |
| Perm. operating height ASL | 2000 m  |
| EMC to standard ... | EN 61131-2 (Zone B) Â |
| Vibration to standard ... | EN 60068-2-6 Â |
| Acc. shock to standard1 | 150 m/s²  |
| Clearance & creepage dist. to | EN 61131-2 Â UL/IEC 61010-2-201 Â |
| Overvoltage category | II Â |
| Pollution degree clear.&creep. | 2 Â |
| Protection type standard | ENÂ 60529 Â |
| Protection type, mounting | Â |
| Protection type, housing | Â |
Potential separation
| Potential isolation 1 between | SC output and module supply  |
| Type of potential isolation 1 | Functional insulation  |
Mechanical data
| Housing material | PC Â |
| Terminal style | plug-in  |
| Height dimension | 110.8 Â mm |
| Width dimension | 12.5 Â mm |
| Depth dimension | 72.5 Â mm |
| Net weight | 36 Â g |
| Gross weight | 45 Â g |
