BMXDRA0805
Discrete Output Module, Modicon X80, 8 No Relay Outputs, 24 To 240V Ac / 24V Dc
/ each
-
-
Secure Shopping
100% Money Back Guarantee.
-
30-DAY RETURNS
30 Days After-sales Return.
-
Worldwide Delivery
Worldwide Fast Shipping.
| Range of product | Modicon X80 |
|---|---|
| product or component type | Discrete output module |
| Discrete output number | 8 EN/IEC 61131-2 |
| discrete output type | Relay |
| Discrete output voltage | 24...240 V 19...264 V AC 12...24 V 10...34 V DC |
| [Ith] conventional free air thermal current | 3 A |
|---|---|
| Insulation resistance | > 10 MOhm 500 V DC |
| Power dissipation in W | 2.7 W |
| Response time on output | |
| Typical current consumption | 79 mA 3.3 V DC |
| MTBF reliability | 2119902 H |
| Output overload protection | Use 1 fast blow fuse per channel or group of channel |
| Output overvoltage protection | Use discharge diode on each output DC Use RC circuit on each output AC Use ZNO surge limiter on each output AC |
| Output short-circuit protection | Use 1 fast blow fuse per channel or group of channel |
| Minimum switching current | 10 mA 5 V DC |
| Electrical durability | AC-15 100000 cycles 220 VA 200...240 V 0.35) AC-12 1000000 cycles 110 VA 110...120 V AC-12 1000000 cycles 220 VA 200...240 V AC-12 1000000 cycles 50 VA 48 V AC-15 1000000 cycles 110 VA 200...240 V 0.35) DC-12 1000000 cycles 24 W 24 V DC-13 1000000 cycles 24 W 24 V AC-15 10000000 cycles 10 VA 110...120 V 0.35) AC-15 10000000 cycles 10 VA 200...240 V 0.35) AC-15 150000 cycles 110 VA 110...120 V 0.35) AC-15 1500000 cycles 50 VA 110...120 V 0.35) AC-15 2000000 cycles 24 VA 48 V 0.35) DC-13 2000000 cycles 10 W 24 V DC-12 300000 cycles 40 W 24 V AC-15 3000000 cycles 50 VA 200...240 V 0.35) AC-12 500000 cycles 110 VA 48 V AC-12 500000 cycles 220 VA 110...120 V AC-15 5000000 cycles 10 VA 48 V 0.35) AC-15 500000 cycles 24 VA 24 V 0.35) AC-12 700000 cycles 50 VA 24 V |
| Status LED | 1 LED (green) module operating (RUN) 1 LED per channel (green) channel diagnostic 1 LED (red) module error (ERR) 1 LED (red) module I/O |
| net weight | 0.32 lb(US) (0.145 kg) |
| IP degree of protection | IP20 |
|---|---|
| Directives | 2014/35/EU - low voltage directive 2014/30/EU - electromagnetic compatibility |
| Environmental characteristic | Corrosion resistance Dust resistant |
| Dielectric strength | 2000 V AC 50/60 Hz 1 min |
| Vibration resistance | 3 gn |
| Shock resistance | 30 gn |
| ambient air temperature for storage | -40…185 °F (-40…85 °C) |
| Ambient air temperature for operation | 32…140 °F (0…60 °C) |
| Relative humidity | 5…95 % 131 °F (55 °C) without condensation |
| Operating altitude | 0...2000 m 2000...5000 m with derating factor |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 2.17 in (5.5 cm) |
| Package 1 Width | 4.33 in (11.0 cm) |
| Package 1 Length | 4.72 in (12.0 cm) |
| Package 1 Weight | 6.24 oz (177.0 g) |
