Quality Assurance
OEM Quality Spare Parts.
- E50ALR1
- Product Name Eaton
- Product Length/Depth -4.22 in
- Product Height -2.25 in
- Product Width -1.54 in
- Product Weight -1.1 lb
- Compliances -RoHS Compliant CE Marked
- Certifications -CSA Certified UL Listed
- Type -Assembly
- Contact Rating -10A at 12 Vac, 1A at 125 Vdc
- Enclosure material -Die cast zinc
- Actuator -Side rotary
- Connection -Screw terminal
- Contact configuration -1 NO-1 NC
- Series -E50
- Operating temperature - max 200 °F
- Operating temperature - min 10 °F
- Light unit voltage 24-120 Vac/dc
- Maximum AC current -10 A continuous
- Maximum DC current -1 A
- LED indicator
