312500
PSSu, electronic module, standard, analogue inputs and outputs, 2inputs, thermocouples with letter codes R, S, B, J, T, E, K, N, voltage with ranges -30 - 30 mV, -60 - 60 mV, -120 - 120 mV, reference temperature via special base modules using integrated Pt1000.
||
-
-
Secure Shopping
100% Money Back Guarantee.
-
30-DAY RETURNS
30 Days After-sales Return.
-
Worldwide Delivery
Worldwide Fast Shipping.
General data
| Approval | CE  cULus Listed  TÜV  |
| Application range | Standard  |
Â
Technical data
Analog inputs
| Number of analogue inputs | 2 Â |
| Type of analogue inputs | Thermocouple  |
| Signal range analog input | Type N  Type R  Type B  Type S  Type T  Type E  Voltage  Type J  Type K  |
| Analog input signal type 1 | Type R Â |
| Analog input Signal range 1 | -50 - 1768 °C  |
| Analog input signal type 2 | Type S Â |
| Analog input Signal range 2 | -50 - 1768 °C  |
| Analog input signal type 3 | Type B Â |
| Analog input Signal range 3 | 600 - 1820 °C  |
| Analog input signal type 4 | Type J Â |
| Analog input Signal range 4 | -210 - 1200 °C  |
| Analog input signal type 5 | Type T Â |
| Analog input Signal range 5 | -200 - 400 °C  |
| Analog input signal type 6 | Type E Â |
| Analog input Signal range 6 | -200 - 1000 °C  |
| Analog input signal type 7 | Type K Â |
| Analog input Signal range 7 | -200 - 1372 °C  |
| Analog input signal type 8 | Type N Â |
| Analog input Signal range 8 | -200 - 1300 °C  |
| Analog input signal type 9 | Voltage  |
| Analog input Signal range 9 | +/-30 mV Â |
| Analog input signal type 10 | Voltage  |
| Analog input Signal range 10 | +/-60 mV Â |
| Analog input signal type 11 | Voltage  |
| Analog input Signal range 11 | +/-120 mV Â |
| Type of input filter | Digital filter  |
| Damping of input filter 1 | 90 dB (60 Hz) Â |
| Value least signif. bit U-Me | 2 µV (+/-60 mV)  4 µV (+/-120 mV)  1 µV (+/-30 mV)  |
| Conversion method analog i/p | Delta sigma  |
| Pot. isolation analog inp./ | Yes  |
Inputs
| Potential isolation inputs | yes  |
Environmental data
| Climatic suitability to ... | EN 60068-2-30 Â EN 60068-2-2 Â EN 60068-2-1 Â EN 60068-2-78 Â EN 60068-2-14 Â |
| Ambient temperature standard | EN 60068-2-14 Â |
| Ambient temperature | 0 - 60  °C |
| Storage temperature standard | EN 60068-2-1/-2 Â |
| Climatic suitability standard | EN 60068-2-30 Â EN 60068-2-78 Â |
| Humidity rating | 93 % r. h. at 40 °C  |
| Condensation permitted? | Not permitted  |
| Perm. operating height ASL | 2000 m  |
| EMC to standard ... | EN 61131-2 Â EN 61000-4-4 Â EN 61000-4-5 Â EN 61000-4-6 Â EN 61000-4-2 Â EN 61000-4-3 Â |
| Vibration to standard ... | EN 60068-2-6 Â |
| Acc. shock to standard1 | 15g  |
| Acc. shock to standard2 | Â |
| Clearance & creepage dist. to | EN 60664-1 Â EN 61131-2 Â |
| Overvoltage category | II Â |
| Pollution degree clear.&creep. | 2 Â |
| Protection type standard | ENÂ 60529 Â |
| Protection type, mounting | Â |
| Protection type, housing | Â |
Mechanical data
| Housing material lower section | PC Â |
| Housing material front plate | PC Â |
| Housing material code | PA Â |
| Height dimension | 76 Â mm |
| Width dimension | 12.6 Â mm |
| Depth dimension | 60.2 Â mm |
| Net weight | 35 Â g |
| Gross weight | 44 Â g |
| Name of coding element | H Â |
| Colour of coding element | Dark grey |
Environment
| REACh compliance | contains min. 1 SVHC-substance  |
| WEEE classifikation (08/2018) | 5 devices (feed size |
Commercial data
| ECLASS version | ECLASS-9.1 Â |
| ECLASS Reference Feature | 27242601 Â |
| ETIM Version | ETIM-7.0 Â |
| ETIM Reference Group | EG000024Â Â |
