328150
PSS u2, electronic module, failsafe, digital inputs and outputs, 2 outputs, relay contacts, N/O, to switch resistive and inductive loads, max. 250 V AC 10 A (AC1), volt-free, switch-off delay configurable, protective coding PSS u2 A CE T available for terminal block, 2-row, terminal block PSS u2 T 8 required (not supplied with the system).
||
-
-
Secure Shopping
100% Money Back Guarantee.
-
30-DAY RETURNS
30 Days After-sales Return.
-
Worldwide Delivery
Worldwide Fast Shipping.
General data
| Approval | CE  cULus Listed  TÜV  |
| Application range | Failsafe  |
Â
Technical data
Electrical data
| Potential isolation U2 | Yes  |
| Permitted loads | Resistive  Inductive  |
Relay outputs
| Number of relay outputs | 2 Â |
| Utilisation cat. AC/DC1 stand. | EN 60947-4-1 Â |
| Voltage AC1 safety cont. | 250 Â V |
| Max. current AC1 safety cont. | 10 Â A |
| Voltage DC1 safety cont. | 24 Â V |
| Max. current DC1 safety cont. | 10 Â A |
| Utilisation cat. AC15/DC13sta. | EN 60947-5-1 Â |
| Voltage AC15 safety cont. | 230 Â V |
| Max. current AC15 safety cont. | 3 Â A |
| Voltage DC13 safety cont. | 24 Â V |
| Safety contacts: AC at UL | 250 VAC G.U. (same polarity) Â |
| Safety contacts: pilot duty | B300, R300 Â |
| Relay contact material | AgCuNi  |
| Addit. contact details relay | + 0.2 µm Au  |
| Pot. isolation relay outputs | Yes  |
Environmental data
| Climatic suitability to ... | EN 60068-2-30 Â EN 60068-2-2 Â EN 60068-2-1 Â EN 60068-2-78 Â EN 60068-2-14 Â |
| Ambient temperature standard | EN 60068-2-14 Â |
| Ambient temperature | 0 - 60  °C |
| Storage temperature standard | EN 60068-2-1/-2 Â |
| Climatic suitability standard | EN 60068-2-78 Â |
| Humidity rating | 93 % r. h. at 40 °C  |
| Condensation permitted? | Not permitted  |
| Perm. operating height ASL | 2000 m  |
| EMC to standard ... | EN 61131-2 (Zone B) Â |
| Vibration to standard ... | EN 60068-2-6 Â |
| Acc. shock to standard1 | 150 m/s²  |
| Clearance & creepage dist.to 2 | EN 60664-1 Â |
| Overvoltage category 2 | III Â |
| Clearance & creepage dist. to | EN 61131-2 Â UL/IEC 61010-2-201 Â |
| Overvoltage category | II Â |
| Pollution degree clear.&creep. | 2 Â |
| Protection type standard | ENÂ 60529 Â |
| Protection type, mounting | Â |
| Protection type, housing | Â |
Potential separation
| Potential isolation 1 between | RL output and RL output  |
| Type of potential isolation 1 | Safe separation  |
| Potential isolation 2 between | RL output and periphery supply  |
| Type of potential isolation 2 | Safe separation  |
| Potential isolation 3 between | RL output and module supply  |
| Type of potential isolation 3 | Safe separation  |
| Potential isolation 4 between | Periphery and module supply  |
| Type of potential isolation 4 | Functional insulation  |
Mechanical data
| Housing material | PC Â |
| Terminal style | plug-in  |
| Height dimension | 110.8 Â mm |
| Width dimension | 25 Â mm |
| Depth dimension | 72.5 Â mm |
| Net weight | 93 Â g |
| Gross weight | 110 Â g |
Environment
| REACh compliance | contains min. 1 SVHC-substance  |
| WEEE classifikation (08/2018) | 5 devices (feed size |
Commercial data
| ECLASS version | ECLASS-9.1 Â |
| ECLASS Reference Feature | 27242604 Â |
| ETIM Version | ETIM-7.0 Â |
| ETIM Reference Group | EG000024Â Â |
