M4NN-DV-12
Meter, DC Volts, 1/32 DIN, 4-Digit, 5-24VDC, PNP Open Collector Output
-
-
Secure Shopping
100% Money Back Guarantee.
-
30-DAY RETURNS
30 Days After-sales Return.
-
Worldwide Delivery
Worldwide Fast Shipping.
| Display method | 4-digit 7-segment LED |
|---|---|
| Character height | 11mm |
| Max. display Range | -1999 to 9999 |
| Measurement | DC voltage |
| Input specification | -600-600V, -200-200V, -100-100V, -20-20V, -10-10V, -2-2V, -1-1V, -200-200mV |
| Power Factor Display | Power Factor Display |
| Power supply | 5-24VDC  |
| Output_Main Output(Comparative Value) | PNP open collector (OUT1, GO, OUT2) |
| Max. allowable input | -110 to 110% of the rated measurement input range(when not using minus input: -10 to 110%) |
| Display accuracy | •23℃±5℃ - ±0.1% F.S. ±2-digit •-10 to 50℃ - ±0.5% F.S. ±3-digit |
| Display cycle | 0.1 to 5.0 sec (selectable by 0.1 sec) |
| A/D conversion method | Practical oversampling using successive approximation ADC |
| Sampling cycle | 50ms (resolution 1/12,000) |
| Environment_Ambient temperature | -10 to 50℃, storage: -20 to 60℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Insulation type | Double insulation or reinforced insulation(mark:  , dielectric strength between the measuring input part and the power part: 1kV) |
| Weight | Approx. 83.6g(approx. 46.8g) |
