Applicable fluid | (Pneumatic type) Air, Non-corrosive gas |
---|---|
Pressure port | R1/8 |
Connection type | Cable type(cable type cable: 3m) |
Pressure type | Compound pressure |
Rated pressure range | -101.3 to 100.0kPa |
Option output | Voltage(1-5VDC âŽâ) output |
Power supply | 12-24VDC @(=) ±10%(ripple P-P: max. 10%) |
Current consumption | Max. 15mA |
Protection structure | IP40 |
Approval | @(EAC) |
Material | Front/Rear case: PBT, Pressure port: Nickel plated brass |
Environment_Ambient temperature | 0 to 50ââÆ, storage: -10 to 60ââÆ |
Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
Sold separately | Sensor connector wire mount plug(CNE-P04-YG) |
Weight | Approx. 60g(approx. 26g) |
