Display method | 4-digit 7-segment LED |
---|---|
Control method | ON/OFF, P, PI, PD, PID |
Input specification | Thermocouple: K(CA), J(IC), E(CR), T(CC), B(PR), R(PR), S(PR), N(NN), C(TT), G(TT), L(IC), U(CC), Platinel II RTD: DPt100Ω, DPt50Ω, JPt100Ω, Cu100Ω, Cu50Ω, Nikel 120Ω Analog: 0-100mV, 0-5V, 1-5V, 0-10V 0-20mA, 4-20mA |
Sampling cycle | 50ms |
Control output 1 | SSR drive(11VDC ) [ON/OFF, phase, cycle] |
Option input | CT, Digital(DI-1) |
Option output | Alarm 1/2, Transmission(DC4-20mA) |
Power supply | 100-240VAC~ 50/60Hz |
Protection structure | IP65(front panel) |
Display accuracy_RTD | â¢At room temperature(23â±5â):(PV ±0.3% or ±1â, select the higher one) ±1-digit â¢Out of room temperature:(PV ±0.5% or ±2â, select the higher one) ±1-digit |
Display accuracy_Thermocouple | â¢At room temperature(23â±5â):(PV ±0.3% or ±1â, select the higher one) ±1-digit â¢Out of room temperature:(PV ±0.5% or ±2â, select the higher one) ±1-digit |
Display accuracy_Analog | â¢At room temperature(23â±5â): ±0.3% F.S. ±1-digit â¢Out of range of room temperature: ±0.5â% F.S. ±1-digit |
Display accuracy_CT input | ±5% F.S. ±1-digit |
Hysteresis(adjustable sensitivity) | RTD/Thermocouples: 1 to 100â/â(0.1 to 100.0â/â) variable Analog: 1 to 100-digit |
Proportional band | 0.1 to 999.9â/â(0.1 to 999.9%) |
Integral time | 0 to 9999 sec |
Derivative time | 0 to 9999 sec |
Control period | Relay output, SSR drive output: 0.1 to 120.0 sec Current output or SSR drive output selectable: 1.0 to 120.0 sec |
Manual reset | 0.0 to 100.0% |
Environment_Ambient temperature | -10 to 50â, storage: -20 to 60â |
Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
Insulation type | Double insulation or reinforced insulation(mark: , dielectric strength between the measuring input part and the power part: 2kV) |
Weight | Approx. 150g(approx. 105g) |
