TM171EP27R
Expansion Module, Modicon M171/M172/M173, Performance, 27 Io
/ each
-
-
Secure Shopping
100% Money Back Guarantee.
-
30-DAY RETURNS
30 Days After-sales Return.
-
Worldwide Delivery
Worldwide Fast Shipping.
| Range of product | Modicon M171/M172 |
|---|---|
| product or component type | Additional I/O module |
| Product specific application | HVAC and pumping solution |
| Total inputs/outputs | 27 |
| Discrete input number | 8 |
| Discrete output number | 3 relay outputs SPST with same common 2 relay outputs SPST with same common 2 relay outputs SPDT with independent common |
| Discrete output current | 8 A relay SPDT 5 A relay SPST |
| Analogue input number | 2 analog input NTC 4 configurable |
| Analogue output number | 3 voltage/current 0…10 V or 4…20 mA 2 open collector/current 1 kHz, 12 V, 35 mA or 4…20 mA |
| Number of port | 1 CAN port - screw terminal block |
|---|---|
| Input/output number | 6 analog input 5 analog output 8 digital input 7 digital output 1 high-speed counter |
| Discrete input logic | Sink or source (positive/negative) |
| Discrete input voltage | 24 V AC/DC 48 V DC |
| Discrete input current | 2.5 mA |
| Input impedance | 20 kOhm |
| Analogue input type | Voltage 0...5 V ratiometric) current 4...20 mA impedance 0...1500 hOhm impedance 0...300 daOhm direct input NTC temperature probe - 50...110 °C 0.1 °C extended) voltage 0...10 V Pt 1000 temperature probe - 200...800 °C 0.1 °C NTC temperature probe - 40...150 °C 0.1 °C |
| Sensor power supply | 5 V DC 50 mA 12 V DC 150 mA |
| [Us] rated supply voltage | 24 V AC 48 V |
| Realtime clock | Without clock at -4…131 °F (-20…55 °C) |
| Display type | Without display |
| Overvoltage category | II |
| Mounting support | DIN rail |
| Width | 5.51 in (140 mm) |
| Height | 4.33 in (110 mm) |
| Depth | 2.43 in (61.6 mm) |
| net weight | 0.42 lb(US) (0.19 kg) |
| Directives | 86/188/EEC - physical agents (noise) directive 2006/95/EC - low voltage directive |
|---|---|
| Standards | EN/IEC 60730 |
| Product certifications | CE cURus EAC CSA |
| Ambient air temperature for operation | -4…131 °F (-20…55 °C) UL 60730-1 |
| ambient air temperature for storage | -40…185 °F (-40…85 °C) |
| Relative humidity | 10…90 % non-condensing |
| IP degree of protection | IP20 |
| Pollution degree | 2 |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 5.12 in (13.000 cm) |
| Package 1 Width | 3.58 in (9.100 cm) |
| Package 1 Length | 7.28 in (18.500 cm) |
| Package 1 Weight | 16.65 oz (472.000 g) |
| Unit Type of Package 2 | S02 |
| Number of Units in Package 2 | 6 |
| Package 2 Height | 5.91 in (15.000 cm) |
| Package 2 Width | 11.81 in (30.000 cm) |
| Package 2 Length | 15.75 in (40.000 cm) |
| Package 2 Weight | 6.74 lb(US) (3.055 kg) |
