BMXDRA0804T
Discrete Output Module, Modicon X80, 8 No Relay Outputs, 100 To 150V Dc, Extended Temperature
/ each
-
-
Secure Shopping
100% Money Back Guarantee.
-
30-DAY RETURNS
30 Days After-sales Return.
-
Worldwide Delivery
Worldwide Fast Shipping.
| Range of product | Modicon X80 |
|---|---|
| product or component type | Discrete output module |
| Product specific application | Extended temperature |
| Discrete output number | 8 EN/IEC 61131-2 |
| discrete output type | Relay |
| Discrete output voltage | 100...150 V DC |
| Insulation resistance | > 10 MOhm 500 V DC |
|---|---|
| Power dissipation in W | 3.17 W |
| Response time on output | |
| Typical current consumption | 61 mA 3.3 V DC 104 mA 24 V DC |
| Current consumption | |
| MTBF reliability | 2800000 H |
| Output overload protection | Use 1 fast blow fuse per channel or group of channel |
| Output overvoltage protection | Use discharge diode on each output DC |
| Output short-circuit protection | Use 1 fast blow fuse per channel or group of channel |
| Maximum switching current | 0.3 A |
| Minimum switching current | 100 mA 5 V DC |
| Mechanical durability | 20000000 cycles |
| Electrical durability | DC-12 100000 cycles 37 W 125 V DC-13 100000 cycles 12 W 125 V |
| Status LED | 1 LED (green) module operating (RUN) 1 LED per channel (green) channel diagnostic 1 LED (red) module error (ERR) 1 LED (red) module I/O |
| net weight | 0.32 lb(US) (0.145 kg) |
| IP degree of protection | IP20 |
|---|---|
| Directives | 2014/35/EU - low voltage directive 2014/30/EU - electromagnetic compatibility |
| Environmental characteristic | Gas resistant class Gx Gas resistant class 3C4 Dust resistant class 3S4 Sand resistant class 3S4 Salt resistant level 2 Mold growth resistant class 3B2 Fungal spore resistant class 3B2 |
| Dielectric strength | 2000 V AC 50/60 Hz 1 min |
| Vibration resistance | 3 gn |
| Shock resistance | 30 gn |
| ambient air temperature for storage | -40…185 °F (-40…85 °C) |
| Ambient air temperature for operation | -13…158 °F (-25…70 °C) |
| Relative humidity | 5…95 % 131 °F (55 °C) without condensation |
| protective treatment | Conformal coating |
| Operating altitude | 0...2000 m 2000...5000 m with derating factor |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 2.17 in (5.500 cm) |
| Package 1 Width | 4.33 in (11.000 cm) |
| Package 1 Length | 4.92 in (12.500 cm) |
| Package 1 Weight | 6.98 oz (198.000 g) |
| Unit Type of Package 2 | S02 |
| Number of Units in Package 2 | 15 |
| Package 2 Height | 5.91 in (15.000 cm) |
| Package 2 Width | 11.81 in (30.000 cm) |
| Package 2 Length | 15.75 in (40.000 cm) |
| Package 2 Weight | 6.25 lb(US) (2.835 kg) |
