AUTONICS

sfd-m3b-m20 AUTONICS

sfd-m3b-m20
left swipe Rotate image right swipe

In Stock (2 Available)

SFD-M3B-M20

Safety Door Switch, Metal head, 3NC, Terminal, M20 Gland port size, 250VAC/6A, 250VDC/0.6A, IP67(IEC standard, except head)

SWITCHES

||

AUTONICS

5.00 10

10 Review(s)
$85.98 $71.65 / each
1
SFD-M3B-M20
AUTONICS
FACTORY SEALED
  • Quality-checked industrial automation parts
  • Secure ordering with responsive customer support
  • Worldwide shipping for critical replacement parts
Fast Delivery
Top Brands
Worldwide Delivery
Secure Transaction
Add To Cart Buy Now

  • Quality Assurance

    OEM Quality Spare Parts.

  • Secure Shopping

    100% Money Back Guarantee.

  • 30-DAY RETURNS

    30 Days After-sales Return.

  • Worldwide Delivery

    Worldwide Fast Shipping.

Contact composition

B3

Load voltage and current

Resistive load: 6A/250VAC~, 0.6A/250VDC

Inductive load: AC-15 3A/240VAC~,DC-13 0.27A/250VDC

Direct opening forceMin. 80N
Direct opening gap Min. 10mm
Operating speed0.05 to 1m/s
Operating frequencyMax. 20/min
Applicable wire (0.5 to 0.75mm²)
Insulation100MΩ or more (wavemeter level 500VDC)
Short circuit current100A
Lifespan_ElectricalMin. 100,000 operations (240VAC~ 6A)
Longevity_CoMin. 1,000,000 operations
TemperatureOperation: -30 to 70℃, storage: -40 to 70℃
Ambient humidityOperation: 35 to 90%RH, storage: 35 to 90%RH
Protective structureIP67 (according to IEC standard, except header)
Connection typeThe cable has an M20 jack
MaterialHead part: zinc, shell part: polyamide 6, operating key: SUS304
Sold separatelyKey
Weight110g
