TM5SDO4T
Discrete Output Module, Modicon Tm5, 4 Do, 24V Dc, 0.5A, 3 Wires
/ each
-
-
Secure Shopping
100% Money Back Guarantee.
-
30-DAY RETURNS
30 Days After-sales Return.
-
Worldwide Delivery
Worldwide Fast Shipping.
| Range of product | Modicon TM5 |
|---|---|
| product or component type | Discrete output module |
| Discrete output number | 4 |
| discrete output type | Transistor |
| Range compatibility | Modicon LMC058 PacDrive LMC motion controller Modicon M258 |
|---|---|
| Product compatibility | PacDrive LMC Pro 2 PacDrive LMC Pro PacDrive LMC Eco Logic controller Motion controller |
| Output voltage | 24 V DC |
| Output voltage limits | 20.4...28.8 V |
| discrete output logic | Source |
| Current per channel | 0.5 A |
| Maximum current per output common | 2 A |
| Colour | White |
| Peak output current | 12 A |
| Switching frequency | |
| Response time | |
| Maximum leakage current | 5 µA when switched off |
| Protection type | Reverse polarity protection Short-circuit protection Overload protection |
| Isolation | 500 Vrms AC insulation between channel and bus No insulation between channels |
| Maximum voltage drop | |
| Maximum supply current for sensors | 500 mA |
| Current consumption | 20 mA 24 V DC input/output 32 mA 5 V DC bus |
| Maximum power dissipation in W | 0.86 W |
| Local signalling | 1 LED green power supply 1 LED red power supply 4 LEDs yellow output status |
| Electrical connection | 3 wires |
| marking | CE |
| net weight | 0.06 lb(US) (0.025 kg) |
| Standards | IEC 61131-2 CSA C22.2 No 213 UL 508 CSA C22.2 No 142 |
|---|---|
| Product certifications | CSA GOST-R cULus C-Tick |
| Ambient air temperature for operation | 14…131 °F (-10…55 °C) without derating horizontal installation) 14…140 °F (-10…60 °C) with derating factor horizontal installation) 14…122 °F (-10…50 °C) vertical installation) |
| ambient air temperature for storage | -40…158 °F (-40…70 °C) |
| Relative humidity | 5…95 % without condensation |
| IP degree of protection | IP20IEC 61131-2 |
| Pollution degree | 2 IEC 60664 |
| Operating altitude | 0...2000 m |
| Storage altitude | 0.00…9842.52 ft (0…3000 m) |
| Vibration resistance | 1 gn 8.4…150 Hz DIN rail 3.5 mm 5…8.4 Hz DIN rail |
| Shock resistance | 15 gn 11 ms |
| Electromagnetic compatibility | Electrostatic discharge immunity test, 4 kV on contact IEC 61000-4-2 Electrostatic discharge immunity test, 8 kV in air IEC 61000-4-2 Susceptibility to electromagnetic fields, 1 V/m 2...2.7 GHz IEC 61000-4-3 Susceptibility to electromagnetic fields, 10 V/m 80...2000 MHz IEC 61000-4-3 Electrical fast transient/burst immunity test, 1 kV I/O IEC 61000-4-4 Electrical fast transient/burst immunity test, 1 kV shielded cable IEC 61000-4-4 Electrical fast transient/burst immunity test, 2 kV power lines IEC 61000-4-4 1.2/50 µs shock waves immunity test, 0.5 kV differential mode IEC 61000-4-5 1.2/50 µs shock waves immunity test, 1 kV common mode IEC 61000-4-5 Conducted RF disturbances IEC 61000-4-6 Conducted and radiated emissions CISPR 11 |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 0.79 in (2.000 cm) |
| Package 1 Width | 2.36 in (6.000 cm) |
| Package 1 Length | 4.13 in (10.500 cm) |
| Package 1 Weight | 1.34 oz (38.000 g) |
| Unit Type of Package 2 | S02 |
| Number of Units in Package 2 | 97 |
| Package 2 Height | 5.91 in (15.000 cm) |
| Package 2 Width | 11.81 in (30.000 cm) |
| Package 2 Length | 15.75 in (40.000 cm) |
| Package 2 Weight | 8.86 lb(US) (4.017 kg) |
